052 AC2
| TECHNIC SPECIFICATIONS – TECHNIC INFORMATIONS | |
| PTO CODE – PTO CODE | 052 AC2 |
| VEHICLE BRAND – TRUCK BRAND | BMC, CHRYSLER, FORD, IVECO, MERCEDES |
| MAIN TRANSMISSION MODEL – GEARBOX MODEL | ZF 9 S 109-186, ZF 9 S 1110, ZF 9 S 1115, ZF 9 S 1310, ZF 16 S 109(13 31 ) |
| CONNECTION DIRECTION – MOUNTING SIDE | FROM THE TAIL / REAR |
| PTO FEATURE – PTO TYPE | DOUBLE GEAR – AIR / DOUBLE THREAD – PNEUMATIC |
| Conversion Rate / Ratio | 1.25 |
| OUTPUT TORQUE – OUTLET TORQUE | 250 NM |
| POWER – POWER (KW) ( 1000 RPM) | 26 kW |
| WEIGHT-WEIGHT | 14.5KG |
| DIRECTION OF ROTATION – ROTATION SENSE | LEFT / LEFT |
| GEAR TYPE | FLAT/FLAT |
BROCHURE: Brochure
